Whelen Parmetheus LED Drop In Replacement Light PAR36, 14V Landing

Whelen Parmetheus LED Drop In Replacement Light PAR36, 14V Landing

Brand: Whelen

Product Code: 01-0771424-10
Availability: In Stock

Whelen Parmetheus LED Drop In Replacement Light PAR36, 14V Landing

LED lighting is the ideal technology for aviation applications. Whelen LED
lights are time and field-tested for reliability and long-life performance under
the tough conditions required by Fire, Emergency, DOT and Law Enforcement
professionals around the world.

Part Number Model Description Power Beam
01-0771424-10 PLED1L Par36 LED Drop-In Replacement, 14V Landing (Spot Light) 1.2A @ 14V 10 º Spot
01-0771424-15 PLED1T Par36 LED Drop-In Replacement, 14V Taxi (Spreader Optic) 1.2A @ 14V 40 º Spreader Optics
01-0771424-20 PLED2L Par36 LED Drop-In Replacement, 28V Landing (Spot Light) 0.6A @ 28V 10 º Spot
01-0771424-25 PLED2T Par36 LED Drop-In Replacement, 28V Taxi (Spreader Optic) 0.6A @ 28V 40 º Spreader Optics



FEATURES:

  • Direct replacement for outdated PAR-36 Halogen and HID lamps.
  • First FAA Approved PAR-36 Super-LED for Aviation applications.
  • Available in Landing and Taxi versions.
  • Polycarbonate, replaceable, hard-coated outer lens.
  • Whelen TIR™ (Total Internal Reflector) technology, combining spot and flood optical combination, resulting in superior intensity and effectiveness.
  • Convenient “Drop-In” design for ease of installation:
    • Power wiring attaches to brass screw terminals.
    • Weight is virtually identical to previous lamps.
    • Assembly design includes clocking notch.
  • Moisture resistant providing stable light output for thousands of trouble-free operating hours.
  • Proudly designed and manufactured in the USA.
  • Low current and lightweight.
  • Metal, heat dissipating coated housing.
  • Three year warranty.



Write a review

Your Name:


Your Review: Note: HTML is not translated!

Rating: Bad           Good

Enter the code in the box below:



File Name Size
Parmetheus PMA list (all models) 188.39KiB
PMA List 91.71KiB
Whelen Parmetheus Data Sheet 323.52KiB
